MQH-1329CSP3

MMIC 13 - 29 GHz 90° Hybrid Coupler

The MQH-1329CSP3 is a MMIC 13 - 29 GHz quadrature hybrid. Passive GaAs MMIC technology allows production of smaller constructions that replace larger form factor circuit board constructions. The MQH-1329CSP3 exhibits excellent amplitude balance with broadband quadrature phasing between output ports. Low variation allows for accurate simulations using the provided S4P file taken from measured production units. Tight fabrication tolerances allow for less unit to unit variation than traditional splitter/combiner technologies.

Product Variant : MQH-1329CSP3
Sorted by: No sorting applied
MQH-1329CSP3
Hybrid
13290.60.6233.50 x 3.50 mmReleased
EVB-MQH-1329
Hybrid
1329----Released

Technical Resources
