Marki Microwave connectorized RF/microwave diplexers divide or combine signals by frequency into low and high pass ports while offering broad frequency coverage, low insertion loss, high out of band rejection, and high isolation. Marki diplexers are resonance-free, making them suitable for antenna sharing between transmit and receive paths, satellite payloads, and spectrum monitoring.
Diplexer
Lowpass Band: - - 0.04 GHz Highpass Band: 0.05 - - GHz Isolation: 24 dB
Broadband Diplexer 21.5 - 40 GHz
Lowpass Band: - - 30.61 GHz Highpass Band: 20.61 - - GHz Isolation: 50 dB
Broadband Diplexer 16 - 32 Ghz
Lowpass Band: - - 32.99 GHz Highpass Band: 24.37 - - GHz Isolation: 40 dB
Passive MMIC 7 GHz Diplexer
Lowpass Band: - - 7.96 GHz Highpass Band: 7.47 - - GHz Isolation: 45 dB
Diplexer
Lowpass Band: - - 3.77 GHz Highpass Band: 2.61 - - GHz Isolation: 25 dB
Passive MMIC DC-6 GHz Diplexer/Reflectionless Filter
Lowpass Band: - - - GHz Highpass Band: - - - GHz Isolation: 58 dB
Diplexer
Lowpass Band: - - 4.81 GHz Highpass Band: 3.55 - - GHz Isolation: 30 dB
Passive MMIC DC-4 GHz Diplexer/Reflectionless Filter
Lowpass Band: - - - GHz Highpass Band: - - - GHz Isolation: 38 dB
Passive MMIC 3 GHz Diplexer/Reflectionless Filter
Lowpass Band: - - - GHz Highpass Band: - - - GHz Isolation: 47 dB
Diplexer
Lowpass Band: - - 4.67 GHz Highpass Band: 2.08 - - GHz Isolation: 25 dB
Diplexer
Lowpass Band: - - 3.13 GHz Highpass Band: 0.66 - - GHz Isolation: 24 dB
Diplexer
Lowpass Band: - - 4.81 GHz Highpass Band: 0.41 - - GHz Isolation: 24 dB
Broadband Diplexer
Lowpass Band: - - 5.96 GHz Highpass Band: 6.91 - - GHz Isolation: 45 dB
Broadband Diplexer 14 - 30 GHz
Lowpass Band: - - 22.15 GHz Highpass Band: 13.15 - - GHz Isolation: 50 dB
