Mixers - M1-0620NE-1

M1-0620NE-1

Double-Balanced Mixers

M1 double balanced mixers are hybrid assemblies that have been hand-tuned to feature low conversion loss and high isolations and a DC IF response. M1 mixers have generally been replaced with MM1 mixers with superior performance, repeatability, and availability. M1 mixers are still used in legacy systems and are suitable for laboratory use.

Sorted by: No sorting applied


M1-0620ME-2		Legacy	6	20	6	10	13	5.5	40	15	-	15.24 x 8.13 mm	NRND
M1-0620ME-1	Request Quote	Legacy	6	20	6	10	13	5.5	40	15	-	15.24 x 8.13 mm	NRND
M1-0620NE-2		Legacy	6	20	6	13	16	6.5	40	17	-	15.24 x 8.13 mm	NRND
M1-0620NE-1	Request Quote	Legacy	6	20	6	13	16	5.5	40	18	-	15.24 x 8.13 mm	NRND
M1-0620SE-2	Request Quote	Legacy	6	20	6	19	22	5.5	40	24	-	15.24 x 8.13 mm	NRND
