Evaluation Board Amplifiers

EVB-AMM-9619P

Evaluation Board, 2-26GHz Surface Mount LO Driver Amplifier

This is the evaluation board for the AMM-9619PSM. The AMM-9619PSM is a surface-mount amplifier suitable for use as a single tone driver or general-purpose gain block. It can drive an L or H diode mixer from 2 to 26 GHz. This amplifier also has exceptionally low input and output reflections, and excellent gain flatness in-band. The AMM-9619PSM is packaged in a compact 4 mm QFN for surface mount integration onto printed circuit boards.
