HLM-40CH

High Power 40GHz Limiter

The HLM-40 is a high-power GaAs Schottky diode signal limiter featuring high IP3 and high-power handling. It offers low insertion loss and low return loss from DC through Ka band and has a typical 1dB compression point of 15dBm. Its high-power handling makes it ideal for protecting sensitive components and for applications requiring high linearity.

Product Variant : HLM-40CH
Sorted by: No sorting applied
HLM-40U

-

040122164201513.21 x 14.22 mmReleased
HLM-40CH

-

0400.52618420151.38 x 1.17 mmReleased
