APM-7099CH

0.01GHz – 20 GHz Low Phase Noise Amplifier

The APM-7099 is a broadband distributed, low phase noise driver amplifier designed to provide a saturated +25 dBm output power with low DC power consumption. This amplifier uses GaAs HBT technology for low phase noise, and is optimized to drive our NLTL multiplier line. It can also provides sufficient power to drive the LO port of an S-diode mixer from 10 MHz to 15 GHz or of an H or L diode mixer from 10 MHz to 20 GHz. This amplifier can be operated with a variety of bias conditions for both low power and high-power applications.

Product Variant : APM-7099CH
Sorted by: No sorting applied
APM-7099PA
Driver
Distributed
Low Phase Noise
0.012014525242328.5 x 15 mmReleased
APM-7099CH
Driver
Distributed
Low Phase Noise
0.01201452524232.28 x 1.40 mmReleased
