MMIQ-0106HCSM-2

Passive GaAs MMIC IQ Mixer

MMIQ-0106HCSM is a high linearity, passive GaAs MMIC IQ mixer. This is an ultra-broadband mixer spanning 1.5 to 5.5 GHz on the RF and LO ports with an IF from DC to 3 GHz. Up to 33 dB of image rejection is available due to the excellent phase and amplitude balance of its on-chip LO quadrature hybrid. The MMIQ 0106HCSM is available in a 5x5 mm ceramic QFN package. Evaluation boards are available.

Product Variant : MMIQ-0106HCSM-2
Sorted by: No sorting applied
EVB-MMIQ-0106HC
Standard IQ
------------Released
MMIQ-0106HCSM-2
Standard IQ
1.55.503162011336222ADM-8007PSM5 x 5 mmReleased
