Surface Mount Fixed Filters

MFLP-00010PSM

Passive GaAs MMIC 4.5 GHz Lowpass Filter

The MFLP-00010PSM is a passive MMIC surface mount 4.5 GHz lowpass filter that is an ideal solution for small form factor, high rejection filtering. Passive GaAs MMIC technology allows production of smaller filter constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit-to-unit variation than traditional filter technologies. The MFLP-00010PSM is available as a 5x5mm plastic QFN. Low unit to unit variation allows for accurate simulations using the provided S2P file taken from measured production units.
