MBAL-0104SM

Passive MMIC 1-4GHz Surface Mount Balun

The MBAL-0104SM is a GaAs passive MMIC balun in a 4mm QFN surface mount package. It features excellent amplitude and phase balance across its 1 to 4 GHz frequency range that offers a 2:1 impedance ratio. The 4mm QFN package is a lead free, RoHS compliant package compatible with standard leaded and lead-free solder reflows. SMA connectorized evaluation packages are available. The MBAL-0104SM is an excellent choice for balanced amplifiers, clock distribution, and higher order Nyquist sampling in analog to digital converters.

Product Variant : MBAL-0104SM
Sorted by: No sorting applied
EVAL-MBAL-0104
Banded
2:114------Released
MBAL-0104SM
Banded
2:114022.58334 x 4 mmReleased
MBAL-1040-TR
Banded
2:114022.58334 x 4 mmReleased
