ADM-10711PSM

8-12 GHz Banded Low Noise Amplifier

The ADM-10711PSM is a broadband low noise amplifier covering 8 to 12 GHz. Designed for ultra-low power consumption, it operates from a single 3 V supply at only 8 mA bias current while delivering 29.1 dB small-signal gain with a typical noise figure of just 1.4 dB. Packaged in a compact 3 mm QFN package, the ADM-10711PSM is ideal for front-end applications that demand high gain with minimal added noise and minimal DC power draw. Measured small-signal S-parameters are provided to support accurate system simulations.

Product Variant : ADM-10711PSM
Sorted by: No sorting applied
EVB-ADM-10711P
LNA
812------Released
ADM-10711PSM
LNA
81229.11.4-1533 x 3 mmReleased
