MSW2-00002CH

4-50 GHz MMIC GaAs PIN SPDT Switch

The MSW2-00002CH is a reflective, single-pole double throw (SPDT) switch. The switch operates from 4 GHz to 50 GHz with average insertion loss and isolation of 1.0 dB and 48 dB respectively. The MSW2-00002CH requires positive and negative 5V supply inputs to control switch states. This switch has a 50-Ohm characteristic impedance. The MSW2-00002CH is available as a wire-bondable die.

Product Variant : MSW2-00002CH
Sorted by: No sorting applied
MSW2-00002CH
SPDT
450153413.10 x 2.40 mmReleased
