MQH-0920CH

MMIC 9-20GHz Quadrature Hybrid

The MQH-0920 is a MMIC 9 GHz – 20 GHz quadrature (90°) hybrid. Passive GaAs MMIC technology allows production of smaller constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit to unit variation than traditional quadrature hybrid technologies. The MQH-0920 is available as a wire bondable chip. Low unit to unit variation allows for accurate simulations using the provided S4P file taken from measured production units. Applications include single sideband upconverters, image rejection downconverters, IQ modulators, balanced amplifiers, microwave correlators, and microwave Butler matrices.

Product Variant : MQH-0920CH
Sorted by: No sorting applied
MQH-0920CH
Hybrid
9200.552222.28 x 1.25 mmReleased
