HLM-100001CH

High Power DC - 10GHz Limiter

The HLM-100001CH is a high-power GaAs Schottky diode signal limiter featuring high IP3 over a broad DC-10GHz bandwidth. It offers low insertion loss and excellent return loss from DC through X band and has a typical 1 dB compression point of 11 dBm. Its high power handling makes it ideal for protecting sensitive components and for applications requiring high linearity. It is available as a wire-bondable die.

Product Variant : HLM-100001CH
Sorted by: No sorting applied
HLM-100001CH

-

0100.8228.5--111.17 x 1.38 mmReleased

Technical Resources
