IQ Mixers - MMIQ-0218LCH-1

MMIQ-0218LCH-1

Low LO Drive Passive GaAs MMIC IQ Mixer

MMIQ-0218L is a low LO drive, passive GaAs MMIC IQ mixer that operates across a 9:1 bandwidth. This is an ultra-broadband mixer spanning 2 to 18GHz on the RF and LO ports with an IF from DC to 3 GHz. Up to 40 dB of image rejection is available due to the excellent phase and amplitude balance of its on-chip LO quadrature hybrid. Both wire bondable die and connectorized modules are available.

Sorted by: No sorting applied


MMIQ-0218LXPC	Standard IQ	2	18	3	13	20	8	27	58	18	ADM1-8007APC	20.32 x 20.32 mm	Released
MMIQ-0218LCH-2	Standard IQ	2	18	3	13	20	8	27	58	18	ADM-5974CH	4.13 x 2.28 mm	Released
MMIQ-0218LCH-1	Standard IQ	2	18	3	13	20	8	27	58	18	ADM-5974CH	4.13 x 2.28 mm	Released
