MFB-3300CH

Passive MMIC 26-40GHz Bandpass Filter

The MFB-3300 is a passive MMIC bandpass filter. It is a low loss integrated filter that passes the Ka (26-40GHz) band. Passive GaAs MMIC technology allows production of smaller filter constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit to unit variation than traditional filter technologies. The MFB-3300 is available as a wire bondable chip. Low unit to unit variation allow for accurate simulations using the provided S2P file taken from measured production units.

Product Variant : MFB-3300CH
Sorted by: No sorting applied
MFB-3300CH
Bandpass
18.3525.3826.3032.1839.3740.7945.061.33.13 x 1.25 mmReleased

Technical Resources
