AMM-9025CH

0.01 - 65GHz mmWave GaAs Driver Amplifier

The AMM-9025CH is a wideband distributed low noise amplifier capable of providing 14 dB gain from 10MHz to 65 GHz and a low 2.8 dB typical noise figure from 7 to 30GHz. The ADM-9025CH is an ideal linear signal amplifier for applications requiring low power consumption and small form-factors. AMM-9025CH is DC coupled with the low end limited by the blocking capacitors. The amplifier has excellent return losses and gain flatness in a small wirebondable 1.75 x 1.2 mm die.

Product Variant : AMM-9025CH
Sorted by: No sorting applied
AMM-9025CH
mm-wave
0.000165142.8-26141.75x1.2mmReleased
