AMM-11059CH

0.01 to 50 GHz, High Frequency Distributed Power Amplifier

The AMM-11059CH is a wideband GaAs distributed amplifier covering 0.01 to 50 GHz, delivering 12 dB small-signal gain with high output power and linearity. It provides up to +27 dBm saturated output power, with output IP3 up to +35 dBm. Operating from a 12 V supply at 220 mA typical current, the amplifier is internally matched to 50 Ω at both the RF input and output ports. These features make it well-suited for wideband driver stages in RF/mmWave front ends, test and measurement instrumentation, electronic warfare, and general-purpose broadband gain block applications.

Product Variant : AMM-11059CH
Sorted by: No sorting applied
AMM-11059CH
Driver
mm-wave
0501272735-1.8 x 1.38 mmReleased
