MQH-1840CSP3

MMIC 18 - 40 GHz 90° Hybrid Coupler

The MQH-1840CSP3 is a MMIC 18 - 40 GHz quadrature hybrid. Passive GaAs MMIC technology allows production of smaller constructions that replace larger form factor circuit board constructions. The MQH-1840CSP3 exhibits excellent amplitude balance with broadband quadrature phasing between output ports. Low variation allows for accurate simulations using the provided S4P file taken from measured production units. Tight fabrication tolerances allow for less unit to unit variation than traditional splitter/combiner technologies.

Product Variant : MQH-1840CSP3
Sorted by: No sorting applied
EVB-MQH-1840
Hybrid
1840----Released
MQH-1840CSP3
Hybrid
18400.60.2273.50 x 3.50 mmReleased

Technical Resources
