Port Diagram
A top-down x-ray view of the MMD-1030LCSM’s CSM package outline drawing is shown below. The MMD-1030LCSM should only be used in the forward direction, with the input and output ports given in Port Functions.
Sales: 408-778-9952 | General: 408-778-4200 | Fax: 408-778-4300
Sales & Customer Support: [email protected]
Tech Support: [email protected]
Device Overview
General Description
The MMD-1030LCSM is a MMIC doubler fabricated with GaAs Schottky diodes. This part operates over a 5 to 15 GHz input frequency range or a doubled output frequency range of 10 to 30 GHz. It features excellent conversion loss, superior isolations, and harmonic suppressions across a broad bandwidth. It is available as a 3x3mm QFN and connectorized evaluation board.
Features
- High Fundamental Rejection
- Low 2F Conversion Loss
- Low Input Drive
Applications
- Test and Measurement Equipment
- LO signal chain
- High frequency synthesis
Functional Block Diagram
Part Ordering Options
| Part Number | Description | Package | Green Status | Product Lifecycle | Export Classification |
|---|---|---|---|---|---|
| MMD-1030LCSM | GaAs MMIC Doubler | QFN | REACH RoHS | Released | EAR99 |
| EVB-MMD-1030LC | Evaluation Board, GaAs MMIC 10 - 30 GHz Doubler | EVB | REACH RoHS | Released | EAR99 |
| Part Number | Description | Package | Green Status | Product Lifecycle | Export Classification |
|---|---|---|---|---|---|
| MMD-1030LCSM | GaAs MMIC Doubler | QFN | REACH RoHS | Released | EAR99 |
| EVB-MMD-1030LC | Evaluation Board, GaAs MMIC 10 - 30 GHz Doubler | EVB | REACH RoHS | Released | EAR99 |
MMD-1030LCSM
GaAs MMIC Doubler
Table Of Contents
- Device Overview
- Port Configuration and Functions
- Revision History
- Specifications
- Mechanical Data
- Footprint Image
- Evaluation Board
Revision History
| Revision Code | Revision Date | Comment |
|---|---|---|
| - | 2023-02-01 | Datasheet Initial Release |
| A | 2026-02-26 | ESD Class Added |
MMD-1030LCSM
GaAs MMIC Doubler
Port Configuration and Functions
Port Functions
| Port | Function | Description | DC Equivalent Circuit |
|---|---|---|---|
| GND | Ground | CSM Package ground path is provided through the ground paddle. |  |
| Pin 2 | 1F Input | Input 1x Frequency Port. Pin 2 is DC open, and AC matched to 50 Ohms from 5 to 15 GHz for the CSM Package. |  |
| Pin 8 | 2F Output | 2x Input Frequency output port. Pin 8 is DC open, and AC matched to 50 Ohms from 10 to 30 GHz for the CSM package. | |
MMD-1030LCSM
GaAs MMIC Doubler
Specifications
Absolute Maximum Ratings
The Absolute Maximum Ratings indicate limits beyond which damage may occur to the device. All Absolute Maximum Ratings are individual and should not be met in parallel. If these limits are exceeded, the device may be inoperable or have a reduced lifetime.
| Parameter | Maximum Rating | Unit |
|---|---|---|
| Maximum Operating Temperature | 100 | °C |
| Maximum Storage Temperature | 125 | °C |
| Minimum Operating Temperature | -55 | °C |
| Minimum Storage Temperature | -65 | °C |
| Power Handling, at any Port (100°C) | 20 | dBm |
| Power Handling, at any Port (25°C) | 25 | dBm |
Package Information
| Parameter | Details | Rating |
|---|---|---|
| ESD | 250 to < 500 Volts | HBM Class 1A |
| Dimensions | - | 3 x 3 mm |
| Moisture Sensitivity Level | - | MSL 1 |
Recommended Operating Conditions
The Recommended Operating Conditions indicate the limits, inside which the device should be operated, to guarantee the performance given in Electrical Specifications Operating outside these limits may not necessarily cause damage to the device, but the performance may degrade outside the limits of the electrical specifications. For limits, above which damage may occur, see Absolute Maximum Ratings.
| Parameter | Min | Nominal | Max | Unit |
|---|---|---|---|---|
| Operating Temperature | -55 | 25 | 100 | °C |
| Input Power | 5 | 7 | 11 | dBm |
MMD-1030LCSM
GaAs MMIC Doubler
Electrical Specifications
The electrical specifications apply at TA=+25°C in a 50Ω system. Typical data shown is for the connectorized EVB package doubler used in the forward direction with a +7 dBm sine wave input. Min and Max limits apply only to our connectorized units and are guaranteed at TA=+25°C.
| Parameter | Test Conditions | Minimum Frequency (GHz) | Maximum Frequency (GHz) | Min | Typ | Max | Unit |
|---|---|---|---|---|---|---|---|
| Conversion Loss | Second Harmonic Output | 10 | 30 | - | 12.5 | 16 | dB |
| Input Frequency Range | - | - | - | 5 | - | 15 | GHz |
| Input Power | - | - | - | 5 | 7 | 11 | dBm |
| Isolation, 1F 1 | Input = 5 - 15 GHz Output = 5 - 15 GHz | 5 | 15 | - | 44 | - | dB |
| Isolation, 3F 2 | Input = 5 – 10 GHz Output = 15 - 30 GHz | 15 | 30 | - | 56 | - | dB |
| Isolation, 4F 3 | Input = 5 – 7.5 GHz Output = 20 - 30 GHz | 20 | 30 | - | 31 | - | dB |
| Output Frequency Range | - | - | - | 10 | - | 30 | GHz |
| Suppression, 1F 4 | Input = 5 – 15 GHz Output = 5 - 15 GHz | 5 | 15 | - | 31 | - | dBc |
| Suppression, 3F 5 | Input = 5 – 10 GHz Output = 15 - 30 GHz | 15 | 30 | - | 43 | - | dBc |
| Suppression, 4F 6 | Input = 5 – 7.5 GHz Output = 20 - 30 GHz | 20 | 30 | - | 17 | - | dBc |
| Parameter | Test Conditions | Minimum Frequency (GHz) | Maximum Frequency (GHz) | Min | Typ | Max | Unit |
|---|---|---|---|---|---|---|---|
| Conversion Loss | Second Harmonic Output | 10 | 30 | - | 12.5 | 16 | dB |
| Input Frequency Range | - | - | - | 5 | - | 15 | GHz |
| Input Power | - | - | - | 5 | 7 | 11 | dBm |
| Isolation, 1F 1 | Input = 5 - 15 GHz Output = 5 - 15 GHz | 5 | 15 | - | 44 | - | dB |
| Isolation, 3F 2 | Input = 5 – 10 GHz Output = 15 - 30 GHz | 15 | 30 | - | 56 | - | dB |
| Isolation, 4F 3 | Input = 5 – 7.5 GHz Output = 20 - 30 GHz | 20 | 30 | - | 31 | - | dB |
| Output Frequency Range | - | - | - | 10 | - | 30 | GHz |
| Suppression, 1F 4 | Input = 5 – 15 GHz Output = 5 - 15 GHz | 5 | 15 | - | 31 | - | dBc |
| Suppression, 3F 5 | Input = 5 – 10 GHz Output = 15 - 30 GHz | 15 | 30 | - | 43 | - | dBc |
| Suppression, 4F 6 | Input = 5 – 7.5 GHz Output = 20 - 30 GHz | 20 | 30 | - | 17 | - | dBc |
[1][2][3] Isolation is defined as the harmonic power relative to the 1F fundamental input power.
[4][5][6] Suppressions and isolations measured with an input source with >60dBc (relative to fundamental input) harmonic suppression. Suppression is defined as the harmonic power relative to the 2F doubled output power.
MMD-1030LCSM
GaAs MMIC Doubler
Typical Performance Plots
MMD-1030LCSM
GaAs MMIC Doubler
Mechanical Data
MMD-1030LCSM
GaAs MMIC Doubler
Footprint Image
Download : Footprint Drawing
MMD-1030LCSM
GaAs MMIC Doubler
Evaluation Board - Outline Drawing
