The T3H-20G is a high performance mixer featuring LO/RF from 10 MHz to 20 GHz and IF from 10 MHz to 18 GHz. As with all T3 mixers, this mixer offers unparalleled nonlinear performance in terms of IIP3, P1dB, and spurious performance with a flexible LO drive requirement from +15 dBm to +25 dBm. The T3H-20G is offered in connectorized, surface mount, and drop-in style packaging, suitable for any type of system level integration. The T3H-20G is a form-fit-function replacement for the obsolete T3H-20, built using GaAs diodes instead of Si.
N/A
| Part Number | Description | Package | Green Status | Product Lifecycle | Export Classification |
|---|---|---|---|---|---|
| T3H-20GLCTG-2 | Two-Tone-Terminator .01 - 20 GHz Mixer | CTG | REACH RoHS | Released | EAR99 |
| T3H-20GICTG-2 | Two-Tone-Terminator .01 - 20 GHz Mixer | CTG | REACH RoHS | Released | EAR99 |
| T3H-20GLCTG-1 | Two-Tone-Terminator .01 - 20 GHz Mixer | CTG | REACH RoHS | Released | EAR99 |
| T3H-20GICTG-1 | Two-Tone-Terminator .01 - 20 GHz Mixer | CTG | REACH RoHS | Released | EAR99 |
| Part Number | Description | Package | Green Status | Product Lifecycle | Export Classification |
|---|---|---|---|---|---|
| T3H-20GLCTG-2 | Two-Tone-Terminator .01 - 20 GHz Mixer | CTG | REACH RoHS | Released | EAR99 |
| T3H-20GICTG-2 | Two-Tone-Terminator .01 - 20 GHz Mixer | CTG | REACH RoHS | Released | EAR99 |
| T3H-20GLCTG-1 | Two-Tone-Terminator .01 - 20 GHz Mixer | CTG | REACH RoHS | Released | EAR99 |
| T3H-20GICTG-1 | Two-Tone-Terminator .01 - 20 GHz Mixer | CTG | REACH RoHS | Released | EAR99 |
T3H-20GLCTG-2
Two-Tone-Terminator .01 - 20 GHz Mixer
| Revision Code | Revision Date | Comment |
|---|---|---|
| - | 2020-08-25 | Initial Release |
| A | 2023-12-21 | Revised conversion loss test conditions in electrical specifications table. |
T3H-20GLCTG-2
Two-Tone-Terminator .01 - 20 GHz Mixer
| Port | Function | Description | DC Equivalent Circuit |
|---|---|---|---|
| IF | IF | The IF port is DC blocked and AC matched to 50 Ohms from 10 MHz to 18 GHz. |  |
| LO | LO | The LO port is DC short to ground and AC matched to 50 Ohms from 10 MHz to 20 GHz. Blocking capacitor is optional. |  |
| RF | RF | The RF port is DC short to ground and AC matched to 50 Ohms from 10 MHz to 20 GHz. Blocking capacitor is optional. | |
T3H-20GLCTG-2
Two-Tone-Terminator .01 - 20 GHz Mixer
| Parameter | Maximum Rating | Unit |
|---|---|---|
| LO DC Current | 1 | Amp |
| Maximum Operating Temperature | 100 | °C |
| Maximum Storage Temperature | 125 | °C |
| Minimum Operating Temperature | -55 | °C |
| Minimum Storage Temperature | -65 | °C |
| RF DC Current | 1 | Amp |
| RF Power Handling (RF+LO), (L -Version) | 25 | dBm |
| Parameter | Details | Rating |
|---|---|---|
| ESD | 250 to < 500 Volts | HBM Class 1A |
| Dimensions | - | 8.13 x 8.13mm |
| Moisture Sensitivity Level | - | MSL 1 |
| Parameter | Min | Nominal | Max | Unit |
|---|---|---|---|---|
| LO Input Power | 15 | - | 25 | - |
T3H-20GLCTG-2
Two-Tone-Terminator .01 - 20 GHz Mixer
Specifications guaranteed from -55 to +100°C, measured in a 50Ω system.
| Parameter | Test Conditions | Min | Typ | Max | Unit |
|---|---|---|---|---|---|
| Conversion Loss | LO/RF = 0.01-18 GHz, IF = 91 MHz | - | 9.5 | 15.5 | dB |
| Conversion Loss | RF = 14 GHz, LO = 13.99-0.01 GHz, IF = 0.01-13.99 GHz | - | 9.5 | 15.5 | dB |
| LO-IF Isolation | LO/RF= 0.01-20 GHz | 15 | - | - | dB |
| LO-RF Isolation | LO/RF= 0.01-20 GHz | 15 | - | - | dB |
| IF Frequency Range | - | 0.01 | - | 18 | GHz |
| Input IP3 | - | - | 32 | - | dBm |
| LO-RF Isolation | - | - | 30 | - | dB |
| RF Frequency Range | - | 0.01 | - | 20 | GHz |
| Parameter | Test Conditions | Min | Typ | Max | Unit |
|---|---|---|---|---|---|
| Conversion Loss | LO/RF = 0.01-18 GHz, IF = 91 MHz | - | 9.5 | 15.5 | dB |
| Conversion Loss | RF = 14 GHz, LO = 13.99-0.01 GHz, IF = 0.01-13.99 GHz | - | 9.5 | 15.5 | dB |
| LO-IF Isolation | LO/RF= 0.01-20 GHz | 15 | - | - | dB |
| LO-RF Isolation | LO/RF= 0.01-20 GHz | 15 | - | - | dB |
| IF Frequency Range | - | 0.01 | - | 18 | GHz |
| Input IP3 | - | - | 32 | - | dBm |
| LO-RF Isolation | - | - | 30 | - | dB |
| RF Frequency Range | - | 0.01 | - | 20 | GHz |
