MM1-1850SSM-2

GaAs MMIC Double Balanced Mixer

The MM1-1850SSM is a GaAs MMIC double balanced mixer that operates at high frequency in a proprietary surface mount package. MM1-1850SSM is a K/Ka band mixer that works well as both an up and down converter. This mixer offers exceptionally high frequency RF bandwidth for a surface mount mixer and high spurious suppression. The sister MM1-1850HSM is recommended for lower LO power applications. The MM1-1850SSM is available in a proprietary 4x4 mm package. Evaluation boards are available.

Product Variant : MM1-1850SSM-2
Sorted by: No sorting applied
EVAL-MM1-1850S
Double Balanced
----See plotSee plot-----Released
MM1-1850SSM-2
Double Balanced
185002120287.92828ADM-8007PSM4 x 4 mmReleased

Technical Resources
