Device Overview

General Description

The MFHP-00001PSM family of passive MMIC surface mount highpass filters are an ideal solution for small form factor, high rejection filtering. Passive GaAs MMIC technology allows production of smaller filter constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit-to-unit variation than traditional filter technologies. The MFHP-00001PSM is available as a 4x4mm plastic QFN. Low unit to unit variation allows for accurate simulations using the provided S2P file taken from measured production units.

Photo of MFHP-00001PSM

Features

  • Low Passband Insertion Loss with Fast Roll-off
  • Excellent Return Loss
  • High Stop Band Suppression

Applications

N/A

Functional Block Diagram

Block Diagram

Part Ordering Options

Part NumberDescriptionPackageGreen StatusProduct LifecycleExport Classification
MFHP-00001PSMPassive GaAs MMIC 2 GHz Highpass FilterQFN

RoHS

REACH

ReleasedEAR99
EVB-MFHP-00001PEvaluation Board, Passive GaAs MMIC 2GHz Highpass FilterEVB

RoHS

REACH

ReleasedEAR99

Table Of Contents

Revision History

Revision CodeRevision DateComment
-2023-04-01Datasheet Initial Release
A2025-03-03Power Handling Update

Rev: A | Copyright © 2023, 2025 Marki Microwave LLC.

2

Port Configuration and Functions

Port Diagram

A top-down x-ray view of the MFHP-00001PSM package outline drawing is shown below.

Diagram of the port configuration for MFHP-00001PSM

Port Functions

PortFunctionDescriptionDC Equivalent
Circuit
Ground PaddleGround PSM package ground path is provided through the ground paddle and should be connected to RF ground.Equivalent circuit for the Ground
Pin 13Output Pin 13 is DC open to ground for the PSM package.Equivalent circuit for the Output
Pin 3Input Pin 3 is DC open to ground for the PSM package.Equivalent circuit for the Input

Rev: A | Copyright © 2023, 2025 Marki Microwave LLC.

3

Specifications

Absolute Maximum Ratings

The Absolute Maximum Ratings indicate limits beyond which damage may occur to the device. If these limits are exceeded, the device may be inoperable or have a reduced lifetime.

ParameterMaximum RatingUnit
Maximum Operating Temperature 100°C
Maximum Storage Temperature 125°C
Minimum Operating Temperature -55°C
Minimum Storage Temperature -65°C
RF Power Handling 14W

Package Information

ParameterDetailsRating
Dimensions-4 x 4 mm
Moisture Sensitivity Level-MSL 1

Rev: A | Copyright © 2023, 2025 Marki Microwave LLC.

4

Electrical Specifications

The electrical specifications apply at TA=+25°C in a 50Ω system. Typical data shown is for the filter in a PSM package with a sine wave input applied to Pin 3. Min and Max limits are guaranteed at TA=+25°C.

ParameterTest ConditionsMinimum
Frequency
(GHz)
Maximum
Frequency
(GHz)
MinTypMaxUnit
1 dBc Passband 25°C, Input Power = -5.00 dBm Input
2.98 ----GHz
30 dBc Rejection Point 25°C, Input Power = -5.00 dBm Input
1.4 ----GHz
3 dBc Passband 25°C, Input Power = -5.00 dBm Input
1.96 ----GHz
Group Delay 25°C, Input Power = -5.00 dBm Input
- --46-ps
Passband Return Loss 25°C, Input Power = -5.00 dBm Input
- --19-dB

Rev: A | Copyright © 2023, 2025 Marki Microwave LLC.

5

Typical Performance Plots

Typical performance is de-embedded from EVB using AFR.

Insertion Loss (dB) graph for MFHP-00001PSM
Insertion Loss (dB) graph for MFHP-00001PSM
Stop Band Suppression (dB) graph for MFHP-00001PSM
Return Loss (dB) graph for MFHP-00001PSM
Return Loss (dB) graph for MFHP-00001PSM
Band 1 Group Delay (ps) graph for MFHP-00001PSM

Rev: A | Copyright © 2023, 2025 Marki Microwave LLC.

6

MFHP Highpass Family Passband Comparison

Mfhp 000 Xxpsm Passband Comparison Table

Insertion Loss vs Frequency graph for MFHP-00001PSM

Rev: A | Copyright © 2023, 2025 Marki Microwave LLC.

7

Mechanical Data

Rev: A | Copyright © 2023, 2025 Marki Microwave LLC.

8

Rev: A | Copyright © 2023, 2025 Marki Microwave LLC.

9

Evaluation Board - Outline Drawing

Outline Drawing
