MFBP-00183PSM

Passive GaAs MMIC 2.95 - 3.29 GHz Bandpass Filter

The MFBP-00183PSM passive MMIC surface mount bandpass filter is an ideal solution for small form factor, high rejection filtering. The MFBP-00183PSM features a 2.95 - 3.29 GHz 1 dBc passband and 4.3 dB center frequency insertion loss. Passive GaAs MMIC technology allows production of smaller filter constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit-to-unit variation than traditional filter technologies. The MFBP-00183PSM is available as a 5 mm plastic QFN. Low unit to unit variation allows for accurate simulations using the provided S2P file taken from measured production units.

Product Variant : MFBP-00183PSM
Sorted by: No sorting applied
MFBP-00183PSM
Request Quote
Bandpass
2.712.902.953.123.293.383.584.35 x 5 mmReleased
EVB-MFBP-00183P
Request Quote
Bandpass
---------Released
