MFBP-00173PSM

Passive GaAs MMIC 16.8 - 18.2 GHz Bandpass Filter

The MFBP-00173PSM passive MMIC surface mount bandpass filter is an ideal solution for small form factor, high rejection filtering. The MFBP-00173PSM features a 16.8-18.2 GHz 1 dBc passband and 3.3 dB center frequency insertion loss. Passive GaAs MMIC technology allows production of smaller filter constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit-to-unit variation than traditional filter technologies. The MFBP-00173PSM is available as a 5 mm plastic QFN. Low unit to unit variation allows for accurate simulations using the provided S2P file taken from measured production units.

Product Variant : MFBP-00173PSM
Sorted by: No sorting applied
EVB-MFBP-00173P
Bandpass
---------Released
MFBP-00173PSM
Bandpass
16.1216.5616.7717.4618.1818.4918.893.35 x 5 mmReleased

Technical Resources
