MFBP-00160GSM1

Passive Glass 2.9 - 4.7 GHz Surface Mount Bandpass Filter

The MFBP-00160GSM1 surface-mount bandpass filter is an ideal solution for extremely small form factor, high rejection filtering. The MFBP-00160GSM1 features a 2.9-4.7GHz 1dBc passband and 1.2dB center frequency insertion loss. Its advanced glass substrate technology allows production of smaller filter constructions that replace larger form factor circuit board constructions. Tight fabrication ensures tighter unit-to-unit consistency than legacy filter technologies, supporting accurate simulation with the provided S2P data. The MFBP-00160GSM1 is offered in a 4.25 x 7.5mm package.

Product Variant : MFBP-00160GSM1
Sorted by: No sorting applied
EVB-MFBP-00160G
Bandpass
---------Released
MFBP-00160GSM1
Bandpass
2.502.742.853.674.724.975.301.27.50 x 4.25 mmReleased
