Surface Mount Fixed Filters

MFBP-00118CSP3

Passive GaAs MMIC 26.3 - 39.4 GHz Bandpass Filter

The MFBP-00118CSP3 passive MMIC surface mount bandpass filter is an ideal solution for small form factor, high rejection filtering. The MFBP-00118CSP3 features a 26.3-39.4GHz 1dBc passband and 1.4dB center frequency insertion loss. Passive GaAs MMIC technology allows production of smaller filter constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit-to-unit variation than traditional filter technologies. The MFBP-0118CSP3 is available in our 3.5 x 3.5mm CSP3 chip scale package. Low unit to unit variation allows for accurate simulations using the provided S2P file taken from measured production units.
