MFBP-00109CSP3

Passive GaAs MMIC 4 - 6.1 GHz Bandpass Filter

The MFBP-00109CSP3 passive MMIC surface mount bandpass filter is an ideal solution for small form factor, high rejection filtering. The MFBP-00109CSP3 features a 4.0-6.1GHz 1dBc passband and 2.4dB center frequency insertion loss. Passive GaAs MMIC technology allows production of smaller filter constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit-to-unit variation than traditional filter technologies. The MFBP-00109CSP3 is available as a 3.5 mm CSP3. Low unit to unit variation allows for accurate simulations using the provided S2P file taken from measured production units.

Product Variant : MFBP-00109CSP3
Sorted by: No sorting applied
MFBP-00109CSP3
Bandpass
3.143.733.984.946.126.487.162.43.50 x 3.50 mmReleased
EVB-MFBP-00109
Bandpass
---------Released
