MFBP-00108CSP3

Passive GaAs MMIC 2.1 - 4 GHz Bandpass Filter

The MFBP-00108CSP3 passive MMIC surface mount bandpass filter is an ideal solution for small form factor, high rejection filtering. The MFBP-00108CSP3 features a 2.1-4.0GHz 1dBc passband and 2.0dB center frequency insertion loss. Passive GaAs MMIC technology allows production of smaller filter constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit-to-unit variation than traditional filter technologies. The MFBP-00108CSP3 is available as a 3.5 mm CSP3. Low unit to unit variation allows for accurate simulations using the provided S2P file taken from measured production units.

Product Variant : MFBP-00108CSP3
Sorted by: No sorting applied
MFBP-00108CSP3
Bandpass
1.491.822.062.874.014.364.832.03.50 x 3.50 mmReleased
EVB-MFBP-00108
Bandpass
---------Released
