MFBP-00081CSP3

Passive GaAs MMIC 11.99 - 13.94 GHz Bandpass Filter

The MFBP-00081CSP3 passive MMIC surface mount bandpass filter is an ideal solution for small form factor, high rejection filtering. Passive GaAs MMIC technology allows production of smaller filter constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit-to-unit variation than traditional filter technologies. The MFBP-00081CSP3 is available in our 3.5 x 3.5mm CSP3 chip scale package. Low unit to unit variation allows for accurate simulations using the provided S2P file taken from measured production units.

Product Variant : MFBP-00081CSP3
Sorted by: No sorting applied
EVB-MFBP-00081
Bandpass
---------Released
MFBP-00081CSP3
Bandpass
11.2311.7111.9912.9313.9414.2914.833.63.50 x 3.50 mmReleased
