MFBC-00004CSP3

Passive GaAs MMIC 15 - 19.8 GHz Bandpass Filter

The MFBC-00004CSP3 passive MMIC surface mount bandpass filter is an ideal solution for small form factor, high rejection filtering. MFBC-00004CSP3 features a 15-19.8GHz 1dBc passband and 1.8dB center frequency insertion loss. Passive GaAs MMIC technology allows production of smaller filter constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit-to-unit variation than traditional filter technologies. The MFBC-00004CSP3 is available in our 3.5 x 3.5mm CSP3 chip scale package. Low unit to unit variation allows for accurate simulations using the provided S2P file taken from measured production units.

Product Variant : MFBC-00004CSP3
Sorted by: No sorting applied
EVB-MFBC-00004
Bandpass
---------Released
MFBC-00004CSP3
Bandpass
13.5114.6914.9917.2119.7520.2221.551.83.50 x 3.50 mmReleased
