MFB-1445SM

Passive MMIC 13.6-15.1 GHz Bandpass Filter

The MFB-1445SM is a passive MMIC bandpass filter. It is an integrated filter that passes Ku-Band frequencies (13.6-15.1 GHz). Passive GaAs MMIC technology allows production of smaller filter constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit to unit variation than traditional filter technologies. Low unit to unit variation allows for accurate simulations using the provided S2P file taken from measured production units. The MFB-1445SM is available as a 3 X 3 mm QFN package. Evaluation boards are also available.

Product Variant : MFB-1445SM
Sorted by: No sorting applied
MFB-1445SM
Bandpass
12.5313.2813.5114.3015.1315.4117.363.73 x 3 mmReleased
EVAL-MFB-1445
Bandpass
---------Released
