MDPX-0407PSM-2_Passive MMIC 0 - 26.5 GHz Diplexer/Reflectionless Filter

Part Number	Description	Package	Green Status	Product Lifecycle	Export Classification
MDPX-0407PSM-2	Passive MMIC 0 - 26.5 GHz Diplexer/Reflectionless Filter	QFN	RoHS REACH	Released	EAR99
EVB-MDPX-0407P	Passive MMIC DC-4 GHz Diplexer/Reflectionless Filter	EVB	RoHS REACH	Released	EAR99

Part Number	Description	Package	Green Status	Product Lifecycle	Export Classification
MDPX-0407PSM-2	Passive MMIC 0 - 26.5 GHz Diplexer/Reflectionless Filter	QFN	RoHS REACH	Released	EAR99
EVB-MDPX-0407P	Passive MMIC DC-4 GHz Diplexer/Reflectionless Filter	EVB	RoHS REACH	Released	EAR99

Revision History

Revision Code	Revision Date	Comment
-	2023-01-01	Datasheet Initial Release

Port Configuration and Functions

Port Diagram

A top-down x-ray view of the MDPX-0407PSM package outline drawing is shown below. Input to the diplexer is on Pin 9, Pin 4 will be the output after passing through the HPF and Pin 13 will be the output after passing through the LPF.

Diagram of the port configuration for MDPX-0407PSM-2

Port Functions

Port	Function	Description
Ground Paddle	Ground	PSM package ground path is provided through the ground paddle and should be connected to RF ground.
Pin 13	RF Low Band	Pin 13 is DC short to Pin 9 and open to GND and Pin 4.
Pin 4	RF High Band	Pin 4 is DC short to GND and open to the other ports.
Pin 9	Common/Input	Pin 9 is DC short to Pin 13 and open to GND and Pin 4.

Specifications

Absolute Maximum Ratings

The Absolute Maximum Ratings indicate limits beyond which damage may occur to the device. All Absolute Maximum Ratings are individual and should not be met in parallel. If these limits are exceeded, the device may be inoperable or have a reduced lifetime.

Parameter	Maximum Rating	Unit
Maximum Operating Temperature	100	°C
Maximum Storage Temperature	100	°C
Minimum Operating Temperature	-65	°C
Minimum Storage Temperature	-65	°C
RF Power Handling	30	dBm

Package Information

Parameter	Details	Rating
ESD	< 50 Volts	HBM 0Z
Dimensions	-	3 x 3 mm
Moisture Sensitivity Level	-	MSL 1

Electrical Specifications

The electrical specifications apply at TA=+25°C in a 50Ω system. Typical data shown is for the filter in a PSM package with a sine wave input applied to Pin 9 . Min and Max limits are guaranteed at TA=+25°C.

Parameter	Test Conditions	Minimum Frequency (GHz)	Maximum Frequency (GHz)	Min	Typ	Max	Unit
1 dBc High Passband ¹	Temp = 25°C	-	-	0.01	-	-	GHz
3 dBc High Passband ²	Temp = 25°C	-	-	1.66	-	-	GHz
30 dBc High Pass Rejection Point ³	Temp = 25°C	-	-	1.66	-	-	GHz
High Passband Return Loss ⁴	Temp = 25°C	-	-	-	23	-	dB
High Pass Isolation ⁵	Temp = 25°C	-	-	-	31	-	dB
High Pass Group Delay ⁶	Temp = 25°C	-	-	-	186	-	ps
1 dBc Low Passband ⁷	Temp = 25°C	-	-	-	-	5.02	GHz
3 dBc Low Passband ⁸	Temp = 25°C	-	-	-	-	5.16	GHz
30 dBc Low Pass Rejection Point ⁹	Temp = 25°C	-	-	-	-	12.00	GHz
Low Passband Return Loss ¹⁰	Temp = 25°C	-	-	-	6	-	dB
Low Pass Isolation ¹¹	Temp = 25°C	-	-	-	8	-	dB
Low Pass Group Delay ¹²	Temp = 25°C	-	-	-	613	-	ps
Crossover Frequency ¹³	Temp = 25°C	-	-	-	5.27	-	GHz
Common Port Return Loss ¹⁴	Temp = 25°C	-	-	-	17	-	dB
Impedance ¹⁵	Temp = 25°C	-	-	-	50	-	Ω
30 dBc Low Pass Rejection Point	DC to 3	0	3	25	53	-	dB
Common Port Return Loss	7 to 26.5 GHz	7	26	10	14	-	dB
Common Port Return Loss	DC to 4 GHz	0	4	19	23	-	dB
High Pass Filter, Pass Band Insertion Loss	7 to 26.5 GHz	7	26.5	-	0.9	-	dB
High Pass Filter, Pass Band Return Loss	7 to 26.5 GHz	7	26.5	10	14	-	dB
Impedance	-	-	-	-	50	-	Ω
Isolation	3 to 4 GHz	3	4	-	20	-	dB
Isolation	7 to 26.5 GHz	7	26.5	25	38	-	dB
Isolation	DC to 3 GHz	0	3	25	38	-	dB
Low Pass Filter, Pass Band Insertion Loss	DC to 4 GHz	0	4	-	0.9	-	dB
Low Pass Filter, Pass Band Return Loss	DC to 4 GHz	0	4	22	24	-	dB
Low Pass Filter, Stop Band Rejection	7 to 26.5	7	26.5	25	42	-	dB
1 dBc High Passband	-	-	-	7	-	26.5	GHz
1 dBc Low Passband	-	-	-	0	-	4	GHz

Parameter	Test Conditions	Minimum Frequency (GHz)	Maximum Frequency (GHz)	Min	Typ	Max	Unit
1 dBc High Passband ¹	Temp = 25°C	-	-	0.01	-	-	GHz
3 dBc High Passband ²	Temp = 25°C	-	-	1.66	-	-	GHz
30 dBc High Pass Rejection Point ³	Temp = 25°C	-	-	1.66	-	-	GHz
High Passband Return Loss ⁴	Temp = 25°C	-	-	-	23	-	dB
High Pass Isolation ⁵	Temp = 25°C	-	-	-	31	-	dB
High Pass Group Delay ⁶	Temp = 25°C	-	-	-	186	-	ps
1 dBc Low Passband ⁷	Temp = 25°C	-	-	-	-	5.02	GHz
3 dBc Low Passband ⁸	Temp = 25°C	-	-	-	-	5.16	GHz
30 dBc Low Pass Rejection Point ⁹	Temp = 25°C	-	-	-	-	12.00	GHz
Low Passband Return Loss ¹⁰	Temp = 25°C	-	-	-	6	-	dB
Low Pass Isolation ¹¹	Temp = 25°C	-	-	-	8	-	dB
Low Pass Group Delay ¹²	Temp = 25°C	-	-	-	613	-	ps
Crossover Frequency ¹³	Temp = 25°C	-	-	-	5.27	-	GHz
Common Port Return Loss ¹⁴	Temp = 25°C	-	-	-	17	-	dB
Impedance ¹⁵	Temp = 25°C	-	-	-	50	-	Ω
30 dBc Low Pass Rejection Point	DC to 3	0	3	25	53	-	dB
Common Port Return Loss	7 to 26.5 GHz	7	26	10	14	-	dB
Common Port Return Loss	DC to 4 GHz	0	4	19	23	-	dB
High Pass Filter, Pass Band Insertion Loss	7 to 26.5 GHz	7	26.5	-	0.9	-	dB
High Pass Filter, Pass Band Return Loss	7 to 26.5 GHz	7	26.5	10	14	-	dB
Impedance	-	-	-	-	50	-	Ω
Isolation	3 to 4 GHz	3	4	-	20	-	dB
Isolation	7 to 26.5 GHz	7	26.5	25	38	-	dB
Isolation	DC to 3 GHz	0	3	25	38	-	dB
Low Pass Filter, Pass Band Insertion Loss	DC to 4 GHz	0	4	-	0.9	-	dB

Parameter	Test Conditions	Minimum Frequency (GHz)	Maximum Frequency (GHz)	Min	Typ	Max	Unit
Low Pass Filter, Pass Band Return Loss	DC to 4 GHz	0	4	22	24	-	dB
Low Pass Filter, Stop Band Rejection	7 to 26.5	7	26.5	25	42	-	dB
1 dBc High Passband	-	-	-	7	-	26.5	GHz
1 dBc Low Passband	-	-	-	0	-	4	GHz
