Surface Mount Baluns

MBAL-0416SMG

4 - 16 GHz MMIC Isolation Balun

The MBAL-0416SMG is a MMIC surface mount high isolation balun. This balun features excellent amplitude and phase balance across its 4 to 16 GHz frequency range and offers a 2:1 impedance ratio. It has significant isolation, reducing the reflection of unwanted common mode signals. The MBAL-0416SMG is form-fit-function compatible with the BAL-0416SMG and is intended for customers supporting existing designs. For new designs, we recommend the MBAL-0422PSM, which offers improved performance in a compact 1.3 x 2mm DFN package.
