AMM-7199ASM

11-38 GHz GaAs Surface Mount LO Driver Amplifier

The AMM-7199ASM is a surface-mount amplifier suitable for use as a single tone driver or general-purpose gain block. It can drive an L or H diode mixer from 11 to 38 GHz, or S diode mixer from 16 to 34 GHz. This amplifier also has low current draw under RF drive, exceptionally low input and output reflections, and excellent gain flatness in-band. The AMM-7199ASM is packaged in a compact 3mm QFN for surface mount integration onto printed circuit boards.

Product Variant : AMM-7199ASM
Sorted by: No sorting applied
EVB-AMM-7199ASM
mm-wave
Driver
1138------Released
AMM-7199ASM
mm-wave
Driver
11382152129193 x 3 mmReleased

Technical Resources
