AMM-10859PSM

4-45 GHz Broadband Driver Amplifier

The AMM-10859PSM is a wideband pHEMT-based GaAs surface-mount driver amplifier operating from 4 to 45 GHz. This amplifier offers high gain at 21 dB, +19 dBm saturated output power, and strong linearity with output IP3 of +27 dBm. It’s an excellent driver for our H- and S-diode mixers and multipliers, and comes in a compact 3 mm surface-mount package for easy integration onto printed circuit boards.

Product Variant : AMM-10859PSM
Sorted by: No sorting applied
AMM-10859PSM
Driver
Gain Block
44521.26.91927163 x 3 mmReleased
EVB-AMM-10859P
Driver
Gain Block
445------Released

Technical Resources
