Surface Mount Amplifiers

ADM-10721PSM

4-22 GHz Broadband Low Noise Amplifier

The ADM-10721PSM is a broadband low noise amplifier covering 4 GHz to 22 GHz. Optimized for ultra-low power operation in compact systems, it operates from a single 3V supply at just 17mA bias current, providing typically 20 dB of small-signal gain with a typical noise figure of 2.3 dB. The ADM-10721PSM requires no application circuit other than bypass capacitors on the DC supply lines, which simplifies integration and reduces board space. Packaged in a compact 3mm QFN, it is well suited for wideband frontend applications that demand low DC power consumption, high gain, and minimal added noise. Measured small-signal S-parameters are available to support accurate system simulation.
