ADM-10717PSM

18-40 GHz Broadband Low Noise Amplifier

The ADM-10717PSM is a broadband low noise amplifier covering 18 GHz to 40 GHz. Optimized for ultra-low DC power consumption in compact systems, it operates from a single 3 V supply at just 6 mA bias current, providing 16.7 dB of small-signal gain with a typical noise figure of 2.5 dB. The ADM-10717PSM requires no application circuit other than bypass capacitors on the DC supply lines, which simplifies integration and reduces board space. Packaged in a compact 3 mm QFN, it is well suited for wideband front-end applications that demand low power, moderate gain, and minimal added noise. Measured small-signal S-parameters are available to support accurate system simulation.
