ADM-10715PSM

12-22 GHz Banded Low Noise Amplifier

The ADM-10715PSM is a broadband low noise amplifier covering 12 GHz to 22 GHz. Optimized for ultra-low power operation in compact systems, it operates from a single 3 V supply at just 8 mA bias current, providing 25.7 dB of small-signal gain with a typical noise figure of 1.8 dB. The ADM-10715PSM requires no application circuit other than bypass capacitors on the DC supply lines, which simplifies integration and reduces board space. Packaged in a compact 3 mm QFN, it is well suited for wideband front-end applications that demand low DC power consumption, high gain, and minimal added noise. Measured small-signal S-parameters are available to support accurate system simulation.
