ADM-10713PSM

12-18 GHz Banded Low Noise Amplifier

The ADM-10713PSM is a broadband low noise amplifier covering 12 to 18 GHz. Designed for ultra-low power consumption, it operates from a single 3 V supply at only 8 mA bias current while delivering 27.3 dB small-signal gain with a typical noise figure of just 1.6 dB. Packaged in a compact 3 mm QFN package, the ADM-10713PSM is ideal for front-end applications that demand high gain with minimal added noise and minimal DC power consumption. Measured small-signal S-parameters are provided to support accurate system simulations.

Product Variant : ADM-10713PSM
Sorted by: No sorting applied
ADM-10713PSM
LNA
121827.31.6-1533 x 3 mmReleased
EVB-ADM-10713P
LNA
1218------Released
