Port Diagram
A top-down view of the MQH-2R58R5CH package outline drawing is shown below. This MMIC quadrature hybrid is a passive reciprocal device allowing any port to be used as the input. Ports 1 – 4 correspond to the UB package designation.
Sales: 408-778-9952 | General: 408-778-4200 | Fax: 408-778-4300
Sales & Customer Support: [email protected]
Tech Support: [email protected]
Device Overview
General Description
The MQH-2R58R5 is a MMIC 2.5 GHz – 8.5 GHz quadrature (90°) hybrid. Wire bondable 50Ω terminations are available on-chip. Passive GaAs MMIC technology allows production of smaller constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit to unit variation than traditional quadrature hybrid technologies. The MQH-2R58R5 is available as a wire bondable chip or connectorized module. Low variation allows for accurate simulations using the provided S4P file taken from measured production units. Applications include single sideband upconverters, image rejection downconverters, IQ modulators, balanced amplifiers, microwave correlators, and microwave Butler matrices.
Features
- Designed for S/C-band applications
- Excellent amplitude and phase balance
- High isolation
- Low insertion loss
- On-chip 50Ω load terminations
Applications
- Single Sideband Upconverters
- Image Rejection Downconverters
- IQ Modulators
- Balanced Amplifiers
- Microwave Correlators
- Microwave Butler Matrices
Functional Block Diagram
Part Ordering Options
| Part Number | Description | Package | Connectors | Green Status | Product Lifecycle | Export Classification |
|---|---|---|---|---|---|---|
| MQH-2R58R5UB | MMIC 2.5-8.5GHz Quadrature Hybrid | UB | Standard | REACH RoHS | Released | EAR99 |
| Part Number | Description | Package | Connectors | Green Status | Product Lifecycle | Export Classification |
|---|---|---|---|---|---|---|
| MQH-2R58R5UB | MMIC 2.5-8.5GHz Quadrature Hybrid | UB | Standard | REACH RoHS | Released | EAR99 |
MQH-2R58R5UB
MMIC 2.5-8.5GHz Quadrature Hybrid
Table Of Contents
- Device Overview
- Port Configuration and Functions
- Revision History
- Specifications
- Operation
- Mechanical Data
Revision History
| Revision Code | Revision Date | Comment |
|---|---|---|
| - | 2018-08-01 | Datasheet Initial Release |
MQH-2R58R5UB
MMIC 2.5-8.5GHz Quadrature Hybrid
Port Configuration and Functions
Port Functions
Configuration A
| Port | Function | Connector Type | Description | DC Equivalent Circuit |
|---|---|---|---|---|
| GND | Ground | - | Package ground provided through metal housing and outer coax conductor. |  |
| Port 1 | Input | SMAF | Port 1 is DC short to port 2 and open to ground. |  |
| Port 2 | 0° Output | SMAF | Port 2 is DC short to port 1 and open to ground. | |
| Port 3 | 90° Output | SMAF | Port 3 is DC short to port 4 and open to ground. | |
| Port 4 | Isolated | SMAF | Port 4 is DC short to port 3 and open to ground. | |
MQH-2R58R5UB
MMIC 2.5-8.5GHz Quadrature Hybrid
Configuration B
| Port | Function | Connector Type | Description | DC Equivalent Circuit |
|---|---|---|---|---|
| GND | Ground | - | Package ground provided through metal housing and outer coax conductor. | |
| Port 1 | 0° Output | SMAF | Port 1 is DC short to port 2 and open to ground. | |
| Port 2 | Input | SMAF | Port 2 is DC short to port 1 and open to ground. | |
| Port 3 | Isolated | SMAF | Port 3 is DC short to port 4 and open to ground. | |
| Port 4 | 90° Output | SMAF | Port 4 is DC short to port 3 and open to ground. | |
MQH-2R58R5UB
MMIC 2.5-8.5GHz Quadrature Hybrid
Configuration C
| Port | Function | Connector Type | Description | DC Equivalent Circuit |
|---|---|---|---|---|
| GND | Ground | - | Package ground provided through metal housing and outer coax conductor. | |
| Port 1 | 90° Output | SMAF | Port 1 is DC short to port 2 and open to ground. | |
| Port 2 | Isolated | SMAF | Port 2 is DC short to port 1 and open to ground. | |
| Port 3 | Input | SMAF | Port 3 is DC short to port 4 and open to ground. | |
| Port 4 | 0° Output | - | Port 4 is DC short to port 3 and open to ground. | |
MQH-2R58R5UB
MMIC 2.5-8.5GHz Quadrature Hybrid
Configuration D
| Port | Function | Connector Type | Description | DC Equivalent Circuit |
|---|---|---|---|---|
| GND | Ground | - | Package ground provided through metal housing and outer coax conductor. | |
| Port 1 | Isolated | SMAF | Port 1 is DC short to port 2 and open to ground. | |
| Port 2 | 90° Output | SMAF | Port 2 is DC short to port 1 and open to ground. | |
| Port 3 | 0° Output | SMAF | Port 3 is DC short to port 4 and open to ground. | |
| Port 4 | Input | SMAF | Port 4 is DC short to port 3 and open to ground. | |
MQH-2R58R5UB
MMIC 2.5-8.5GHz Quadrature Hybrid
Specifications
Absolute Maximum Ratings
The Absolute Maximum Ratings indicate limits beyond which damage may occur to the device. If these limits are exceeded, the device may be inoperable or have a reduced lifetime.
| Parameter | Maximum Rating | Unit |
|---|---|---|
| Maximum Operating Temperature | 100 | °C |
| Maximum Storage Temperature | 125 | °C |
| Minimum Operating Temperature | -55 | °C |
| Minimum Storage Temperature | -65 | °C |
| RF Power Handling | 10 | W |
Package Information
| Parameter | Details | Rating |
|---|---|---|
| Dimensions | - | 9.93 x 16.26 mm |
MQH-2R58R5UB
MMIC 2.5-8.5GHz Quadrature Hybrid
Electrical Specifications
The electrical specifications apply at Tau=+25°C in a 50Ω system.
| Parameter | Port Configuration | Test Conditions | Minimum Frequency (GHz) | Maximum Frequency (GHz) | Min | Typ | Max | Unit |
|---|---|---|---|---|---|---|---|---|
| Amplitude Balance | A | - | 2.5 | 8.5 | - | 0.4 | 2 | dB |
| Excess Insertion Loss | A | - | 2.5 | 8.5 | - | 2 | 4 | dB |
| Impedance | A | - | 2.5 | 8.5 | - | 50 | - | Ω |
| Isolation | A | - | 2.5 | 8.5 | 14 | 23 | - | dB |
| Mean Coupling | A | - | 2.5 | 8.5 | - | 3 | - | dB |
| Nominal Phase Shift | A | - | 2.5 | 8.5 | - | 90 | - | ° |
| Phase Balance | A | - | 2.5 | 8.5 | - | 3 | 10 | ° |
| VSWR | A | - | 2.5 | 8.5 | - | 1.15 | - |
| Parameter | Port Configuration | Test Conditions | Minimum Frequency (GHz) | Maximum Frequency (GHz) | Min | Typ | Max | Unit |
|---|---|---|---|---|---|---|---|---|
| Amplitude Balance | A | - | 2.5 | 8.5 | - | 0.4 | 2 | dB |
| Excess Insertion Loss | A | - | 2.5 | 8.5 | - | 2 | 4 | dB |
| Impedance | A | - | 2.5 | 8.5 | - | 50 | - | Ω |
| Isolation | A | - | 2.5 | 8.5 | 14 | 23 | - | dB |
| Mean Coupling | A | - | 2.5 | 8.5 | - | 3 | - | dB |
| Nominal Phase Shift | A | - | 2.5 | 8.5 | - | 90 | - | ° |
| Phase Balance | A | - | 2.5 | 8.5 | - | 3 | 10 | ° |
| VSWR | A | - | 2.5 | 8.5 | - | 1.15 | - |
MQH-2R58R5UB
MMIC 2.5-8.5GHz Quadrature Hybrid
Typical Performance Plots
All measurements taken from a connectorized unit in a 50Ω environment. Phase balance spread is shown due to large performance spread. Minimal variance observed in amplitude balance and insertion loss. Performance spread is related to packaging and bond wire inductance variation. On-chip load was not used when taking measurements.
