Device Overview
General Description
The MMD-1030H is a passive double balanced MMIC doubler covering 10 to 30 GHz on the output. It features excellent conversion loss, superior isolations and harmonic suppressions across a broad bandwidth, in a highly miniaturized form factor. Accurate, nonlinear simulation models are available for Microwave Office® and ADS through the Marki Microwave PDK. The MMD-1030H is available as a wire bondable chip or a connectorized package. The MMD-1030H is a superior alternative to Marki Microwave carrier and packaged doublers.
Features
- Compact Chip Style Package (0.054” x 0.046”x0.004”)
- CAD Optimized for Superior Suppressions and Efficiency
- Broadband Performance
- Excellent Unit-to-Unit Repeatability
- Fully nonlinear software models available with Marki PDK for Microwave Office® and ADS
- RoHS Compliant
Applications
N/A
Functional Block Diagram
Part Ordering Options
| Part Number | Description | Package | Connectors | Green Status | Product Lifecycle | Export Classification |
|---|---|---|---|---|---|---|
| MMD-1030HS | GaAs MMIC Doubler | S | Standard | REACH RoHS | Released | EAR99 |
| Part Number | Description | Package | Connectors | Green Status | Product Lifecycle | Export Classification |
|---|---|---|---|---|---|---|
| MMD-1030HS | GaAs MMIC Doubler | S | Standard | REACH RoHS | Released | EAR99 |
MMD-1030HS
GaAs MMIC Doubler
Table Of Contents
- Device Overview
- Port Configuration and Functions
- Revision History
- Specifications
- Operation
- Mechanical Data
- Notes
Revision History
| Revision Code | Revision Date | Comment |
|---|---|---|
| A | 2019-02-01 | Die resized from 1.47 x 0.82 mm2 to 1.38 x 1.17 mm2. CH package tolerance added. |
MMD-1030HS
GaAs MMIC Doubler
Port Configuration and Functions
Port Functions
| Port | Function | Connector Type | Description | DC Equivalent Circuit |
|---|---|---|---|---|
| 2F | 2F | 2.92F | 2x input frequency output port. The output port is DC open and AC matched to 50 Ohms from 10 to 30 GHz. Blocking capacitor is optional. |  |
| F | 1F | SMAF | Input 1x frequency port. The input port is DC open and AC matched to 50 Ohms from 5 to 15 GHz. Blocking capacitor is optional. | |
MMD-1030HS
GaAs MMIC Doubler
Specifications
Absolute Maximum Ratings
| Parameter | Maximum Rating | Unit |
|---|---|---|
| Maximum Operating Temperature | 100 | °C |
| Maximum Storage Temperature | 125 | °C |
| Minimum Operating Temperature | -55 | °C |
| Minimum Storage Temperature | -65 | °C |
| RF Power Handling, 100°C | 20 | dBm |
| RF Power Handling, 25°C | 25 | dBm |
Package Information
| Parameter | Details | Rating |
|---|---|---|
| Dimensions | - | 14.22 x 13.21 mm |
MMD-1030HS
GaAs MMIC Doubler
Electrical Specifications
Specifications guaranteed from -55 to +100°C, measured in a 50Ω system.
| Parameter | Test Conditions | Minimum Frequency (GHz) | Maximum Frequency (GHz) | Min | Typ | Max | Unit |
|---|---|---|---|---|---|---|---|
| Conversion Loss | Second Harmonic Output | 10 | 30 | - | 11.5 | 17 | dB |
| Input Power | 1F=5-15 GHz 2F=10-30 GHz | 5 | 15 | 10 | 14 | 17 | dBm |
| Isolation, 1F 1 | 1F=5-15 GHz 2F=10-30 GHz | 5 | 15 | - | 53 | - | dB |
| Isolation, 3F 2 | 1F=5-15 GHz 2F=10-30 GHz | 10 | 30 | - | 58 | - | dB |
| Isolation, 4F 3 | 1F=5-15 GHz 2F=10-30 GHz | 10 | 30 | - | 29 | - | dB |
| Suppression, 1F 4 | 1F=5-15 GHz 2F=10-30 GHz | 5 | 15 | - | 41 | - | dB |
| Suppression, 3F 5 | 1F=5-15 GHz 2F=10-30 GHz | 10 | 30 | - | 47 | - | dB |
| Suppression, 4F 6 | 1F=5-15 GHz 2F=10-30 GHz | 10 | 30 | - | 22 | - | dB |
| Input Frequency Range | - | - | - | 5 | - | 15 | GHz |
| Output Frequency Range | - | - | - | 10 | - | 30 | GHz |
| Parameter | Test Conditions | Minimum Frequency (GHz) | Maximum Frequency (GHz) | Min | Typ | Max | Unit |
|---|---|---|---|---|---|---|---|
| Conversion Loss | Second Harmonic Output | 10 | 30 | - | 11.5 | 17 | dB |
| Input Power | 1F=5-15 GHz 2F=10-30 GHz | 5 | 15 | 10 | 14 | 17 | dBm |
| Isolation, 1F 1 | 1F=5-15 GHz 2F=10-30 GHz | 5 | 15 | - | 53 | - | dB |
| Isolation, 3F 2 | 1F=5-15 GHz 2F=10-30 GHz | 10 | 30 | - | 58 | - | dB |
| Isolation, 4F 3 | 1F=5-15 GHz 2F=10-30 GHz | 10 | 30 | - | 29 | - | dB |
| Suppression, 1F 4 | 1F=5-15 GHz 2F=10-30 GHz | 5 | 15 | - | 41 | - | dB |
| Suppression, 3F 5 | 1F=5-15 GHz 2F=10-30 GHz | 10 | 30 | - | 47 | - | dB |
| Suppression, 4F 6 | 1F=5-15 GHz 2F=10-30 GHz | 10 | 30 | - | 22 | - | dB |
| Input Frequency Range | - | - | - | 5 | - | 15 | GHz |
| Output Frequency Range | - | - | - | 10 | - | 30 | GHz |
[1][2][3] Isolation is defined as relative to the fundamental input power.
[4] Suppression is relative to doubled output power.
[5][6] Suppression is relative to doubled output power.
MMD-1030HS
GaAs MMIC Doubler
Typical Performance Plots
MMD-1030HS
GaAs MMIC Doubler
Application Circuit
MMD-1030HS
GaAs MMIC Doubler
