Device Overview
General Description
The EQ3-40 passive equalizer is an ideal solution for compensating for low pass filtering effects in RF/microwave and high speed digital systems. This equalizer provides positive slope from DC to 40 GHz with a DC attenuation value of 3 dB and a 50-ohm match maintained over the entire operating range.
Features
- 40 Gb/s Equalizer
- Matched 50 Ohm Impedance on Input and Output Ports
Applications
- Digital Communications
- Signal Integrity
Functional Block Diagram
EQ3-40
Equalizer (40 Gb/s)
Table Of Contents
Revision History
| Revision Code | Revision Date | Comment |
|---|---|---|
| - | 2023-05-18 | Datasheet Initial Release |
EQ3-40
Equalizer (40 Gb/s)
Port Configuration and Functions
Port Functions
| Port | Function | Connector Type | Description | DC Equivalent Circuit |
|---|---|---|---|---|
| GND | Ground | - | Ground provided through metal housing and outer coax conductor. |  |
| Port 1 | Input/Output | - | Port 1 is DC connected to ground through a resistor. DC block is required if voltage present |  |
| Port 2 | Input/Output | - | Port 2 is DC connected to ground through a resistor. DC block is required if voltage present. |  |
EQ3-40
Equalizer (40 Gb/s)
Specifications
Absolute Maximum Ratings
| Parameter | Maximum Rating | Unit |
|---|---|---|
| RF Power Handling | 0.25 | W |
Package Information
| Parameter | Details | Rating |
|---|---|---|
| Weight | - | 9g |
| Dimensions | - | 11.94 x 11.94 mm |
EQ3-40
Equalizer (40 Gb/s)
Electrical Specifications
Specifications guaranteed from -55 to +100°C, measured in a 50Ω system.
| Parameter | Test Conditions | Minimum Frequency (GHz) | Maximum Frequency (GHz) | Min | Typ | Max | Unit |
|---|---|---|---|---|---|---|---|
| Insertion Loss | - | 15 | 15 | - | 1.2 | - | dB |
| Insertion Loss | - | 40 | 40 | - | 1 | - | dB |
| Insertion Loss at DC | - | 0 | 0 | - | 3 | - | dB |
| Risetime/Falltime 1 | - | 0 | 40 | - | 11 | - | ps |
| Return Loss | - | 0 | 40 | - | 18 | - | dB |
| Parameter | Test Conditions | Minimum Frequency (GHz) | Maximum Frequency (GHz) | Min | Typ | Max | Unit |
|---|---|---|---|---|---|---|---|
| Insertion Loss | - | 15 | 15 | - | 1.2 | - | dB |
| Insertion Loss | - | 40 | 40 | - | 1 | - | dB |
| Insertion Loss at DC | - | 0 | 0 | - | 3 | - | dB |
| Risetime/Falltime 1 | - | 0 | 40 | - | 11 | - | ps |
| Return Loss | - | 0 | 40 | - | 18 | - | dB |
[1] Specified as 20%/80%.Amplitude- and phase-matched pairs available; contact factory.
EQ3-40
Equalizer (40 Gb/s)
Typical Performance
EQ3-40
Equalizer (40 Gb/s)
Time Domain Performance Plots
Oscilloscope measurements of the EQ3-40 with a 40 Gb/s PRBS pattern. Bit pattern is measured with a 2⁷-1 PRBS input. Eye diagrams are taken with a 2³¹-1 PRBS input. Input data pattern figure is uncorrelated with the other patterns due to the additional cable length.
