| Parameter | Typ | Unit |
|---|---|---|
| Frequency Range | 6 to 67 | GHz |
| RF Power Handling | 10 | W |
| Directivity | 17 | dB |
| Mean Coupling | 10 | dB |
Summary only – refer to the Electrical Specifications, Absolute Maximum Ratings, and Recommended Operating Range tables for complete details.
Sales: 408-778-9952 | General: 408-778-4200 | Fax: 408-778-4300
Sales & Customer Support: [email protected]
Tech Support: [email protected]
C10-0667
DIRECTIONAL COUPLER
General Description
The C10-0667 is a broadband 6-67 GHz, 10 dB directional coupler. The multisection tri-plate stripline design exhibits excellent coupling flatness and VSWR at all ports. Custom designs are also available, contact the factory for details.
Features
- Ultra Broadband Performance
- Excellent Coupling Flatness
- High Directivity
- Low VSWR
Functional Block Diagram
Electrical Performance Summary
Part Ordering Options
| Part Number | Description | Connectors | Green Status | Product Lifecycle | Export Classification |
|---|---|---|---|---|---|
| C10-0667 | DIRECTIONAL COUPLER | Standard | REACH RoHS | Released | EAR99 |
Table Of Contents
Typical Performance Plots
Specifications
Electrical Specifications
The electrical specifications apply at TA=+25°C in a 50Ω system
| Parameter | Test Conditions | Minimum Frequency (GHz) | Maximum Frequency (GHz) | Min | Typ | Max | Unit |
|---|---|---|---|---|---|---|---|
| Frequency Range | - | 6 | 67 | - | - | - | GHz |
| Amplitude Flatness 1 | - | 6 | 67 | - | 0.8 | - | dB |
| Directivity | - | 30 | 67 | 8 | 13 | - | dB |
| Directivity | - | 6 | 30 | 13 | 17 | - | dB |
| Direct Line Insertion Loss | DC-67 | - | - | - | - | 2.5 | dB |
| Mean Coupling | - | 6 | 67 | - | 10 | - | dB |
| VSWR | - | 30 | 67 | - | 1.5 | - | - |
| VSWR | - | 6 | 30 | - | 1.2 | 1.45 | - |
[1] Deviation from average coupling.
Absolute Maximum Ratings
| Parameter | Maximum Rating | Unit |
|---|---|---|
| RF Power Handling | 10 | W |
| Maximum Operating Temperature | 100 | °C |
| Minimum Storage Temperature | -65 | °C |
| Minimum Operating Temperature | -55 | °C |
| Maximum Storage Temperature | 125 | °C |
Package Information
| Parameter | Details | Rating |
|---|---|---|
| Weight | - | 25g |
| Dimensions | - | 38.1 x 12.7 mm |
Port Configuration and Functions
Port Functions
| Port | Function | Connector Type | Description | DC Equivalent Circuit |
|---|---|---|---|---|
| -10dB | -10dB Coupled Output | 1.85F | -10dB coupled output port. | - |
| IN | RF Input | 1.85F | RF input port. | - |
| ISOL | Isolated | 1.85F | Isolated port. | - |
| OUT | RF Output | 1.85F | RF output port. | - |
Mechanical Data
Outline Drawing
Download : Outline 2D Drawing Outline 3D Drawing Outline 3D STP
Revision History
| Revision Code | Revision Date | Comment |
|---|---|---|
| B | 2020-04-01 | Updated Direct Line IL specs |
