General Description

The ATN10-00110 is a family of precision GaAs MMIC fixed attenuators. These attenuators are an ideal solution for attenuating a signal and they can be used in a wide range of applications. They are ideal for test equipment’s protection and signal overload prevention in various RF circuitry. A 50-ohm match is maintained over the entire operating frequency range.

Photo of ATN10-00110

Features

  • 10dB attenuation DC to 110GHz
  • Return loss: typical 20 dB over theentire band
  • Serialized for traceability

Applications

  • 5G
  • Automotive Radar
  • Test Equipment
  • Amplitude Matching
  • Precision Characterization
  • Wireless Backhaul

Functional Block Diagram

Block Diagram

Part Ordering Options

Part NumberDescriptionPackageConnectorsGreen StatusProduct LifecycleExport Classification
ATN10-00110-2WGaAs MMIC DC to 110GHz Attenuator MStandard

RoHS

REACH

ReleasedEAR99
ATN10-00110-3WGaAs MMIC DC to 110GHz Attenuator MStandard

RoHS

REACH

ReleasedEAR99
ATN10-00110GaAs MMIC DC to 110GHz Attenuator MStandard

RoHS

REACH

ReleasedEAR99

Table Of Contents

Revision History

Revision CodeRevision DateComment
-2020-10-01Initial Datasheet Release
A2020-11-01Updated Outline Drawings

Rev: A | Copyright © 2020 Marki Microwave LLC.

2

Port Configuration and Functions

Port Functions

PortFunctionConnector TypeDescriptionDC Equivalent
Circuit
GNDGround -M package ground provided through metal housing and outer coax conductor.Equivalent circuit for the Ground
Port 1Input/Output -Port 1 and Port 2 are DC connected to each other and ground through a T-network of resistors.Equivalent circuit for the Input/Output
Port 2Input/Output -Port 1 and Port 2 are DC connected to each other and ground through a T-network of resistors.Equivalent circuit for the Input/Output

Rev: A | Copyright © 2020 Marki Microwave LLC.

3

Specifications

Absolute Maximum Ratings

The Absolute Maximum Ratings indicate limits beyond which damage may occur to the device. If these limits are exceeded, the device may be inoperable or have a reduced lifetime.

ParameterMaximum RatingUnit
DC Current, any pin 100mA
Maximum Operating Temperature 100°C
Maximum Storage Temperature 125°C
Minimum Operating Temperature -55°C
Minimum Storage Temperature -65°C
RF Power Handling 12W

Reliability ratings are individual, a combination of stresses (DC current, RF power, and heat) may cause premature failure).

[1] Actual failure observed at 4W at 2 GHz with a baseplate temperature of 23°C. Power handling will derate with frequency and temperature.

Package Information

ParameterDetailsRating
ESD250 to < 500 VoltsHBM Class 1A
WeightPackage name: M14.2g
Dimensions-14.30 x 27.18 mm

Rev: A | Copyright © 2020 Marki Microwave LLC.

4

Electrical Specifications

The electrical specifications apply at TA=+25°C in a 50Ω system. Typical data shown is for the attenuator in a M package with a sine wave input applied to port 1.

ParameterTest ConditionsMinimum
Frequency
(GHz)		 Maximum
Frequency
(GHz)		MinTypMaxUnit
Attenuation -0 110-10.5-dB
Attenuation Flatness -100 110-1.2-dB
Attenuation Flatness -0 81-0.4-dB
Attenuation Flatness -81 100-1-dB
Impedance -0 110-50-Ω
Return Loss -100 110-15-dB
Return Loss -0 81-22-dB
Return Loss -81 100-20-dB

Rev: A | Copyright © 2020 Marki Microwave LLC.

5

Typical Performance Plots

Insertion Loss (dB) graph for ATN10-00110
Return Loss graph for ATN10-00110

Rev: A | Copyright © 2020 Marki Microwave LLC.

6

Mechanical Data

Outline Drawing

Download : Outline 2D Drawing Outline 3D Drawing Outline 3D STP

Outline Drawing
  1. All measurements are typical.
  2. Attach 1.0mm connectors with 45 N-cm (4 in-lb) torque wrench.
