MSW2-00001CH

2-26 GHz MMIC GaAs PIN SPDT Switch

The MSW2-00001CH is a reflective, single-pole double throw (SPDT) switch. The switch operates from 2 GHz to 26 GHz with average insertion loss and isolation of 0.8 dB and 52 dB respectively. The MSW2-00001CH requires positive and negative 5V supply inputs to control switch states. This switch has a 50-Ohm characteristic impedance. The MSW2-00001CH is available as a wire-bondable die.

Product Variant : MSW2-00001CH
Sorted by: No sorting applied
MSW2-00001CH
SPDT
2260.855413.10 x 2.40 mmReleased
