MMD-0415HCH

GaAs MMIC Doubler

The MMD-0415H is a MMIC doubler fabricated with GaAs Schottky diodes. This operates over a guaranteed 2 to 7.5 GHz input frequency range or a doubled output frequency range of 4 to 15 GHz. It features excellent conversion loss, superior isolations and harmonic suppressions across a broad bandwidth. Both the wire bondable die and connectorized units are available.

Product Variant : MMD-0415HCH
Sorted by: No sorting applied
MMD-0415HCH
Doublers
Passive
41527.51127ADM-8007CH1.17 x 1.38 mmReleased
MMD-0415HS
Doublers
Passive
41527.51127ADM1-8007APC14.22 x 13.21 mmReleased
