MM1-1886HCH-2

GaAs MMIC mmWave Double Balanced Mixer

The MM1-1886HCH-2 is a compact, passive double-balanced MMIC mixer engineered for wideband performance. It features excellent 8.5 dB conversion loss, superior isolations, and spurious performance across a broad 18 to 86 GHz RF/LO bandwidth. Low LO drive requirement allows operation at as low as +13 dBm inputs. The MM1-1886H is available as a wire bondable chip or a connectorized package.

Product Variant : MM1-1886HCH-2
Sorted by: No sorting applied
MM1-1886HCH-2
Request Quote
Double Balanced
188602013See plot8.55021.5-2.28x1.38mmReleased
