MMIQ-0626HCH-2

Passive GaAs MMIC IQ Mixer

MMIQ-0626H is a high linearity, passive GaAs MMIC IQ mixer. This is an ultra-broadband mixer spanning 6 to 26 GHz on the RF and LO ports with an IF from DC to 6 GHz. Up to 40 dB of image rejection is available due to the excellent phase and amplitude balance of its on-chip LO quadrature hybrid. Both wire bondable die and connectorized modules are available.

Product Variant : MMIQ-0626HCH-2
Sorted by: No sorting applied
MMIQ-0626HS
Standard IQ
62606132312354124ADM1-8007APC14.22 x 13.21 mmReleased
MMIQ-0626HCH-2
Standard IQ
62606132312354124ADM-5974CH2.28x2.09mmReleased
