MFLP-00040CH

Passive GaAs MMIC 32.4 GHz Lowpass Filter

The MFLP-00040CH is a passive MMIC surface mount lowpass filter that is an ideal solution for small form factor, high rejection filtering. The MFLP-00040CH features a 32.4 GHz 3 dBc cutoff and 32 dB passband return loss. Passive GaAs MMIC technology allows production of smaller filter constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit-to-unit variation than traditional filter technologies. The MFLP-00040CH is available as a wire-bondable die. Low unit to unit variation allows for accurate simulations using the provided S2P file taken from measured production units.

Product Variant : MFLP-00040CH
Sorted by: No sorting applied
MFLP-00040CH
Lowpass
----25.8332.4035.82-1.38 x 1.25 mmReleased
