MFHP-00041CH

Passive GaAs MMIC 31.36 GHz Highpass Filter

The MFHP-00041CH is a passive MMIC surface mount highpass filter that is an ideal solution for small form factor, high rejection filtering. The MFHP-00041CH features a 31.36 GHz 3 dBc cutoff and 21 dB passband return loss. Passive GaAs MMIC technology allows production of smaller filter constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit-to-unit variation than traditional filter technologies. The MFHP-00041CH is available as a wire-bondable die. Low unit to unit variation allows for accurate simulations using the provided S2P file taken from measured production units.

Product Variant : MFHP-00041CH
Sorted by: No sorting applied
MFHP-00041CH
Request Quote
Highpass
28.6131.3633.56----1.31.38 x 1.25 mmReleased
